Hybrid Rubber Running Track Surface | Eco-Friendly & Durable Sports Flooring Solution
- Model
- PU-003
Item specifics
- Color
- red, blue, green, yellow, white, etc
Review
Description
Information
Hybrid Plastic Track Material
The hybrid plastic track adopts a two-layer structure.The bottom layer is an elastic layer of a part of the rubber blended with the whole PU, and the surface layer is a wear-resistant layer of the wear-resistant polyurethane topcoat mixed with EPDMparticles.
Scope Of Application
Universities, technical secondary schools, primary and secondary schools, professional sports venues, plastic runways, semi-circular areas, auxiliary areas, national fitness paths, indoor gymna-sium training runways, amusement parks and pedestrian anti-skid roads.
Product Features
1. Environmentally friendly and non-toxic
2. Good weather resistance
3. Good rebound force
4. Multiple colors
5. Non fading
6. Wear resistant
7. Voltage resistance
8. Shock absorption
Layered Diagram
Material Parameter
| Hybrid Rubber Running Track Material Parameter | |
| Parameter Name | Parameter Value |
Main Ingredients | Polyether Polyol,Isocyanate,EPDM |
| Density | 1-1.3g/cm³ |
Polymer Content | 30-40% |
Shore A Hardness | ≥45 |
Tensile Strength (Mpa) | ≥0.6 |
Fracture Elongation Rate /% | ≥50 |
Vertical Deformation /mm | 1.0-3.0 |
Thickness | Average thickness 13mm, minimum not less than 10mm |
Slope Requirements | Longitudinal slope ≤ 0.1%, transverse slope ≤ 1.0% |
Evenness | The gap under a 2-meter straightedge shall not exceed 3mm. |
Drainage Performance | Non permeable type |
Heavy metals (lead, chromium, cadmium, mercury) /mg/kg | ≤2 |
Flame Retardancy | I |
TVOC Emissions mg/(㎡. h) | ≤5.0 |
Weather Resistance | Aging box 500H, performance qualified |
Nail Resistance | Anti spiked shoes |
Anti Slip Value (BPN. 20 ℃) | 90-110 (Dry Test) |
Ingredient List
Hybrid Rubber Running Track Ingredient List
13mm Plastic Track | |||
Name Of Proportioning Material | Model | Packaging Specifications | Net Weight |
Waterproof Primer | LS-001 | 20L 275mm base diameter * 285mm surface diameter * 362mm height | 20kg/barrel |
Available granules: black granules (2-4mm), red or white EPDM granules (2-4mm) or else color granules | LS-032 | / | 25kg/bag |
Runway material PU | LS-005 | A：200L, B:300L 570mm diameter x 890mm height | A:200kg/barrel,B:300kg/barrel |
| Running Track Topcoat Red/Green/Blue | LS-007 | A：200L, B:250L 570mm diameter x 890mm height | A:200kg/barrel,B:250kg/barrel |
EPDM granules (1-3mm) | LS-026 | / | 25kg/bag |
Eco-friendly Catalytic Agent | LS-009 | 275mm base diameter * 285mm surface diameter * 362mm height or else | 20KG/barrel or else |
Eco-friendly Diluent | LS-010 | 20L or 200L 275mm base diameter * 285mm surface diameter * 362mm height
or 570mm diameter x 890mm height | 20KG/barrel or 200kg/barrel |
| Marking Paint | LS-011 | 5L | 5.1kg/barrel |
| Lead time (within days) | 1-7 days, usually within 24 hours | ||
| Sales Method | Sell all materials for the ingredient list | ||
